Quick Details

  • Condition: New
  • Type: Screw
  • Configuration: Portable
  • Power Source: Diesel
  • Lubrication Style: Lubricated
  • Mute: Lower Noise Level
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: AUGUST
  • Model Number: SCY75
  • Voltage: To prevail in kind
  • Dimension(L*W*H): 3565X2020X2078 MM
  • Weight: 2000 KG
  • Certification: ISO 9001/ISO14001
  • Warranty: 18 Months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Motor power (KW/HP): 4BTA3.9-C125(cummins) 93KW
  • Discharge pressure (Bar): 7 / 8 / 10 / 13 / 14
  • Free air delivery (M3/MIN): 12/10/8.5/11/8.5
  • Air supply outlet(Inch): R1"+R1 1/2"

Packaging & Delivery

Packaging Details: Exported Wooden Cases
Delivery Detail: Shipped in 30 days after payment
Product Description



ModelSCY75ASCY75BSCY75CSCY75DSCY75F
Free air delivery(m3/min)12108.5118.5
cfm424353300388300
l/s200167142183142
Discharge pressure(MPa)0.71.01.30.81.4
bar71013814
psig102145189116203
Ambient temperature(℃)-5~+40
Cooling methodAir cooling
Air supply temperature (℃)Less Than Ambient temperature +15℃
Power (kW/HP)4BTA3.9-C125(cummins) 93KW
Overall dimension (mm)3565X2020X2078
Weight (kg)2000
Air supply out (Inch)R1"+R1 1/2"



IE3 Version Compliance:
   15  18.5  22  30  37  55  75  90  110  132  160  185  200  220  250
Motor Power
     (kw)
   92.1  92.6  93  93.6  93.7  94.3  94.7  95.2  95.4  95.6  95.8  95.7  95.8  95.8  95.8
Efficiency


Main Parts
1 Engine: high-efficiency and energy saving, stable and reliable, durable and with adequate reserve power;

world-renowned CUMMINS engines enjoy worldwide after-sales service system
2 The principal machine adopts twin-screw rotor and is directly connected with diesel engine by highly flexible

coupling. Computer simulates the analysis of torsional vibration, which enables it to output more air with less

energy consumption, providing high reliability, longer service life and low maintenance cost
3 Air-oil separator filter is by German company, ensuring largest filtering area with the same size.



Cooling System
High-performance fin type structure is designed with high-temperature resistance ability, which can run for

long time under extreme cold or hot temperature from-05 C to approx 50 C .



Mobile System
Height-adjustable goose neck design is equipped with outrigger whose height can be also easily adjusted

which is applicable to field works under various conditions .
Vibration isolators are fitted between the engine, compressor and base frame, which can effectively reduce

vibration and ensure stable running
All the movable parts are effectively fixed for further reducing vibration
Energy-saving & Environmental-friendly Design



FAQ



1. Q: What is used for?

  A: Road and building construction, on railway and conservation projects, at drilling and mining sites,

as industrial electricity backup, and for numerous other uses.



2. Q: What is the Pressure?

  A: We can supply pressure 7 / 8 / 10 / 13 BAR



3. Q: Free Air delivery?

  A: From 152 CFM to 424 CFM



4. Q: What is the diesel engine brand?

  A: SCY37 use YUCHAI brand

SCY45/SCY55/SCY75 use Cummins brand



5. Q: Certificate?

  A: ISO 9001:2008, ISO 14000:2004, CE



6. Q:  Delivery time?

   A: 30 days



7. Q: Warranty

  A: 18 months related parts warranty and 2 years air end warranty
